Scanmax F6 is a biometric access control terminal that integrats IP66 level waterproof, video intercom, RFID reader, face recognition and anti-tamper function. It can quickly liveness face detection(LFD) even in the dark, and notify users through three-color indicator lights (green/red/white).

8 inch sun-readable screen. Android 11.0 system can support secondary development. With IP66 waterproof and dustproof function. Support biometric face identification + QR code + IC card reader. HDR wide dynamic detection function.

The product is based on 200W RGB, 200W IR binocular camera, supports WIFI + 10 / 100M network and rich peripheral security interface, to meet the needs of user access control, can realize personnel authentication, personnel entry and exit management and attendance management.


The products are widely applicable to office buildings, office areas, hotels, schools, shopping malls,communities, public services, stations and scenic spot pavilions and other traffic scenarios that need to be used, which is conducive to the realization of intelligent safety control.


Features of Face Recognition Temperature

* Armed with latest RK3566 board,Android 11Os

* Software: basic software with SDK and APl;

* Customized software to scan EU green pass code and MRZ on passport


F6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time AttendanceF6CS Face Recognition Device for Smart Time Attendance


Face recognition all-in-one machine terminal

Product module

F6

Product

features

major function

Access control, attendance, access gate

Usage environment

Indoor, outdoor

4/16

resolution ratio

200 megapixels

200 megapixels

Vertical wide Angle

65°

65°

Horizontal wide Angle

40°

40°

White light supplement

support

Infrared light supplement

support

Core

parameters

system

android 11.0

CPU

RK3566 4x ARM Cortex TM A55up to1.8GHz

SC

Memory 2G,storage 32G

human-computer interaction

display screen

8-inch, Full View,170°IPS LCD, resolution 800* 1280

touch screen

support

Human temperature measurement module [Optional]

Test accuracy: 0.1

test error:<±0.5

Temperature measurement distance: the recommended use distance is 50cm

Operating temperature: 15℃~40

communication model

Ethernet

10/100Mbps Ethernet

WIFI

Compliance with the IEEE802.11b/g/n standard (2.4G)

4G[Optional]

CAT1, domestic full Net

RM

human face

support

IC card[optional]

support

certificate of identification

Network ID card [Optional]

Local ID card needs external connection [optional]

Interface

data interface

USB 2.0*2

electric relay

*1


gorge line

RS4851

Wigan

The 26bit/ 34bit protocol

Go out switch

*1 [Expandable]

Fire linkage

*1 [Expandable]

key

Upgrade key

Source

adapter

DC12V/2A power supply

Environmental requirement

working temperature

-20℃~60

Operating humidity

20%90%(No condensation water drop state)

static electricity ESD

IEC61000-4-2,LEVEL3

levels of protection

IP65
